ELMAP P high-performance
Airborne Laser Mapping Solutions
ELMAP-P
Fully certified wing strut pod
For Cessna 172, 182 & 206 Aircrafts
request a quote
download datasheet

100 - 1600 kHz

pulse rate

10° - 80°

field of view

20 - 250 line/s

scan rate

15 kg

weight

2’100m

Max Operating Altitude

3’000m

Max Swath Width
ELMAP-P

KEY FEATURES

  • Industry-leading field-of-view of 80°
  • Up to 1, 400, 000 shots-per-second on the ground
  • High range up to 2’100 m at 20% reflectance
  • Linear, uniform scan pattern with parallel scan lines
  • High-resolution waveform digitization for every shot
  • Integrated removable data storage on standard high-capacity SSDs
  • Compact size and the lowest power consumption of their class
  • Optionally with internal MEMS IMU
  • STC from US and Canadian FAA’s
  • Friendly price tag

FULL specification

SPECIFICATION ELMAP-P
Ranging method laser pulse time-of-flight, waveform digitization
Measurement range (1) 2500
Ranging precision (2) 0.007 m
Ranging accuracy (3) 0.03 m
Laser pulse rate 100 – 1.600 kHz
Effective measurement rate (4) 90.000 – 1.400.000 meas/s
Data output (5) (6) (7) range, intensity, pulse width for every target/return
Beam divergence (8) 0.3 mrad
Laser eye-safety class Class 3B
Beam deflection polygon mirror scanner
Scan pattern linear parallel scan lines
Field of View 10° – 80°
Scan rate 20 – 250 scans lines/s
Angular accuracy 0.0025°
Operational altitude (9) up to 2100 m
Swath width (10) up to 3000 m
Data storage capacity (11) 1TB internal (2.2 h) | 4TB removable (8.8 h)
  1. To single, flat target perpendicular to beam, entirely covering laser footprint, with 20% diffuse target reflectance at laser wavelength, 40 km visibility, 95% detection probability
  2. Standard deviation one sigma to single flat target perpendicular to beam, entirely covering laser
    footprint, at range of 150 m
  3. RMS one sigma to single, flat target perpendicular to beam, entirely covering laser footprint, with 20% diffuse reflectance, at range of 1200 m
  4. Shots-on-the ground at 80° FOV – each measurement may consist of returns from multiple targets
  5. Derived from recorded waveform data in post-processing; minimum return amplitude required for pulse detection, i.e. targets at large distance, with small cross section, or low reflectance may go undetected
  6. True range is derived in post-processing using RDA (range disambiguation) technology for an unlimited number of range zones
  7. Data gaps and banding between range zones are minimized using Adaptive PRF technology based on Riegl Patent No. WO2016/201469 and used under license
  8. 1/e2 value
  9. Flat surface, 20% reflectance, 30km visibility, 100 kHz PRF, 100% output power, 60° FOV
  10. Flat surface, 85% of max. AGL, 80° FOV
  11. Minimum endurance for continuous (uninterrupted) data acquisition, at maximum data rate

dimensions

ELMAP-P

Side VIEW

REAR VIEW

SPECIFICATION ELMAP-P
Power requirements 18 – 32 VDC, 100 W (avg.)
110 W (max during startup)
Dimensions 753mm length x 233mm max. diameter
Weight 15 kg (incl. pod)
Instrument mounting points

4x BOLT, 1/ 4”-28, STEEL (clamp to wing strut assembly)

1x BOLT, 1/ 2”-20, STEEL (lower block to pod assembly)

4x BOLT, 1/ 4”-28, STEEL (clamp upper to lower block assembly)
Operating conditions 0°C – 40°C, 0 – 5000m MSL
